PlusLib  2.9.0
Software library for tracked ultrasound image acquisition, calibration, and processing.
List of all members | Classes | Public Types | Public Member Functions | Static Public Member Functions | Static Public Attributes | Protected Types | Protected Member Functions | Protected Attributes
vtkPlusParameters Class Reference

This class is used as the basis to store a configuration of generic parameters for any device. This class exists mainly for two reasons: Provide a standard interface for accessing parameters Enable standardized API for operating on parameters. More...

#include <src/PlusDataCollection/vtkPlusParameters.h>

Inheritance diagram for vtkPlusParameters:
Inheritance graph
[legend]
Collaboration diagram for vtkPlusParameters:
Collaboration graph
[legend]

Classes

class  ParameterInfo


Public Types

typedef vtkObject Superclass


Public Member Functions

virtual PlusStatus DeepCopy (const vtkPlusParameters &otherParameters)

virtual const char * GetClassName ()

template<typename T >
PlusStatus GetValue (const std::string &paramName, T &outputValue) const

virtual int IsA (const char *type)

bool IsPending (const std::string &paramName) const

bool IsSet (const std::string &paramName) const

virtual void PrintSelf (ostream &os, vtkIndent indent) VTK_OVERRIDE

virtual PlusStatus ReadConfiguration (vtkXMLDataElement *deviceConfig)

PlusStatus SetPending (const std::string &paramName, bool pending)

template<typename T >
PlusStatus SetValue (const std::string &paramName, T aValue)

virtual PlusStatus WriteConfiguration (vtkXMLDataElement *deviceConfig)


Static Public Member Functions

static int IsTypeOf (const char *type)

static vtkPlusParametersNew ()

static vtkPlusParametersSafeDownCast (vtkObject *o)


Static Public Attributes

static const char * NAME_TAG = "Name"

static const char * PARAMETER_TAG = "Parameter"

static const char * VALUE_TAG = "Value"

static const char * XML_ELEMENT_TAG = "Parameters"


Protected Types

typedef std::map< std::string, ParameterInfoParameterMap

typedef ParameterMap::const_iterator ParameterMapConstIterator

typedef ParameterMap::iterator ParameterMapIterator


Protected Member Functions

ParameterMapConstIterator begin () const

ParameterMapConstIterator end () const

virtual const char * GetXMLElementName ()

 vtkPlusParameters ()

virtual ~vtkPlusParameters ()


Protected Attributes

ParameterMap Parameters


Detailed Description

This class is used as the basis to store a configuration of generic parameters for any device. This class exists mainly for two reasons: Provide a standard interface for accessing parameters Enable standardized API for operating on parameters.

Definition at line 24 of file vtkPlusParameters.h.

Member Typedef Documentation

◆ ParameterMap

typedef std::map<std::string, ParameterInfo> vtkPlusParameters::ParameterMap
protected

Definition at line 41 of file vtkPlusParameters.h.

◆ ParameterMapConstIterator

typedef ParameterMap::const_iterator vtkPlusParameters::ParameterMapConstIterator
protected

Definition at line 43 of file vtkPlusParameters.h.

◆ ParameterMapIterator

typedef ParameterMap::iterator vtkPlusParameters::ParameterMapIterator
protected

Definition at line 42 of file vtkPlusParameters.h.

◆ Superclass

typedef vtkObject vtkPlusParameters::Superclass

Definition at line 58 of file vtkPlusParameters.h.

Constructor & Destructor Documentation

◆ vtkPlusParameters()

vtkPlusParameters::vtkPlusParameters ( )
protected

Definition at line 23 of file vtkPlusParameters.cxx.

◆ ~vtkPlusParameters()

vtkPlusParameters::~vtkPlusParameters ( )
protectedvirtual

Definition at line 29 of file vtkPlusParameters.cxx.

Member Function Documentation

◆ begin()

vtkPlusParameters::ParameterMapConstIterator vtkPlusParameters::begin ( ) const
protected

Return an iterator to the beginning of the parameter space

Definition at line 36 of file vtkPlusParameters.cxx.

◆ DeepCopy()

PlusStatus vtkPlusParameters::DeepCopy ( const vtkPlusParameters otherParameters)
virtual

Copy the values from another imaging parameters

Definition at line 190 of file vtkPlusParameters.cxx.

◆ end()

vtkPlusParameters::ParameterMapConstIterator vtkPlusParameters::end ( ) const
protected

Return an iterator to the end of the parameter space

Definition at line 42 of file vtkPlusParameters.cxx.

◆ GetClassName()

virtual const char* vtkPlusParameters::GetClassName ( )
virtual

◆ GetValue()

template<typename T >
PlusStatus vtkPlusParameters::GetValue ( const std::string &  paramName,
T &  outputValue
) const
inline

Request a stored value by key name

Parameters
paramNamethe key value to retrieve
outputValuethe output variable to write to

Definition at line 84 of file vtkPlusParameters.h.

◆ GetXMLElementName()

virtual const char* vtkPlusParameters::GetXMLElementName ( )
inlineprotectedvirtual

Reimplemented in vtkPlusUsImagingParameters, and vtkPlusCameraControlParameters.

Definition at line 143 of file vtkPlusParameters.h.

◆ IsA()

virtual int vtkPlusParameters::IsA ( const char *  type)
virtual

◆ IsPending()

bool vtkPlusParameters::IsPending ( const std::string &  paramName) const

Request the pending status of a parameter

Parameters
paramNamethe key value to retrieve

Definition at line 155 of file vtkPlusParameters.cxx.

◆ IsSet()

bool vtkPlusParameters::IsSet ( const std::string &  paramName) const

Request the set status of a parameter (whether it is not the default value)

Parameters
paramNamethe key value to retrieve

Definition at line 142 of file vtkPlusParameters.cxx.

◆ IsTypeOf()

static int vtkPlusParameters::IsTypeOf ( const char *  type)
static

◆ New()

static vtkPlusParameters* vtkPlusParameters::New ( )
static

◆ PrintSelf()

void vtkPlusParameters::PrintSelf ( ostream &  os,
vtkIndent  indent
)
virtual

Print the list of supported parameters. For diagnostic purposes only.

Definition at line 48 of file vtkPlusParameters.cxx.

◆ ReadConfiguration()

PlusStatus vtkPlusParameters::ReadConfiguration ( vtkXMLDataElement *  deviceConfig)
virtual

Read main configuration from/to XML data Assumes that the data element passed is the device element, not the root!

Parameters
deviceConfigthe XML element of the device

Definition at line 63 of file vtkPlusParameters.cxx.

◆ SafeDownCast()

static vtkPlusParameters* vtkPlusParameters::SafeDownCast ( vtkObject *  o)
static

◆ SetPending()

PlusStatus vtkPlusParameters::SetPending ( const std::string &  paramName,
bool  pending
)

Set the pending status of a parameter

Definition at line 168 of file vtkPlusParameters.cxx.

◆ SetValue()

template<typename T >
PlusStatus vtkPlusParameters::SetValue ( const std::string &  paramName,
aValue
)
inline

Set a stored value by key name Defined in the header to make it available externally

Parameters
paramNamethe key value to retrieve
aValuethe value to write

Definition at line 109 of file vtkPlusParameters.h.

◆ WriteConfiguration()

PlusStatus vtkPlusParameters::WriteConfiguration ( vtkXMLDataElement *  deviceConfig)
virtual

Write main configuration from/to XML data Assumes that the data element passed is the device element, not the root!

Parameters
deviceConfigthe XML element of the device

Definition at line 105 of file vtkPlusParameters.cxx.

Member Data Documentation

◆ NAME_TAG

const char * vtkPlusParameters::NAME_TAG = "Name"
static

Definition at line 53 of file vtkPlusParameters.h.

◆ PARAMETER_TAG

const char * vtkPlusParameters::PARAMETER_TAG = "Parameter"
static

Definition at line 52 of file vtkPlusParameters.h.

◆ Parameters

ParameterMap vtkPlusParameters::Parameters
protected

Definition at line 143 of file vtkPlusParameters.h.

◆ VALUE_TAG

const char * vtkPlusParameters::VALUE_TAG = "Value"
static

Definition at line 54 of file vtkPlusParameters.h.

◆ XML_ELEMENT_TAG

const char * vtkPlusParameters::XML_ELEMENT_TAG = "Parameters"
static

Definition at line 51 of file vtkPlusParameters.h.


The documentation for this class was generated from the following files:
